A105 Carbon Steel Weld Neck Flange RF Forging DIN Black 150# 300#

Product Details:

Place of Origin:	Hebei,China
Brand Name:	RT
Certification:	CE,ISO,BV,SGS etc
Model Number:	Weld Neck Flange

Payment & Shipping Terms:

Minimum Order Quantity:	1ton
Price:	Negotiable
Packaging Details:	Wooden Case
Delivery Time:	7-30 working days
Payment Terms:	T/T, L/C, D/P
Supply Ability:	600 tons/per month

Contact Now

Detailed Product Description

Type:	Weld Neck Flange	Standard:	ASME/ANSI B16.5
Pressure:	150# 300# 600# 900# 1500# Etc	Size:	1/2″ To 72″
Material:	A105//A105N/Q235	Surface:	Anti-rust Transparent Oiled Or Black Paint
Usage:	Construction Industry/Chemical Industry/Petroleum Field/Nuclear Energy	Technics:	Forged Casting
High Light:	RF Carbon Steel Weld Neck Flange , A105 Carbon Steel Weld Neck Flange , Weld Neck Rf Flange

Forging DIN Black A105 Carbon Steel Raised Face RF Weld Neck Flange

Description:

WN flanges are mainly suitable for butt welding of flanges and pipes. They have high strength and rigidity, reasonable structure, can withstand high temperature, high pressure, repeated bending and temperature fluctuations, and their sealing performance is reliable. Concave-convex sealing surface, nominal pressure 150#~1500#.

Specifications:

Product Name	Forging DIN Black A105 Carbon Steel Raised Face RF Weld Neck Flange
Types	Plate, Welding Neck, Slip on, Blind, Lap joint, Threaded Flange
Face Finish	RF,FF,RTJ,TF,GF
Standard	ANSI	ANSI B16.5 ASME B16.47 series A/B
	DIN	DIN 2631 2573 2527 2565 2641
	GOST	GOST 12820-80,GOST 12821-80,Gost Blind
	EN	EN1092-1:2002
	JIS	JIS B2220-2004, KS D3576, KS B6216,KS B1511-2007,JIS B2261; JIS B8210
	BS	BS4504,BS10 Table D/E
	UNI	UNI 2253-67,UNI6091-67,UNI2276-67,UNI2280-67,UNI6089-67
	SABS	SABS 1123
Material	ANSI	CS A105/SA 105N,SS 304/304L,316/316L Alloy Steel: WHPY45/52/65/80
	DIN	CS RST37.2;S235JR SS 304/304L,316/316L
	GOST	CS CT20;16MN;SS 304/304L,316/316L
	EN	CS RST37.2;S235JR;C22.8SS 304/304L,316/316L
	JIS	CS SS400,SF440,SS 304/304L, 316/316L
	BS	CSRST37.2;S235JR;C22.8;Q235SS 304/304L,316/316L
	UNI	CSRST37.2;S235JR;C22.8;Q235SS 304/304L,316/316L
	SABS	CSRST37.2;S235JR;Q235;SS 304/304L,316/316L
Pressure	ANSI	Class 150, 300, 600, 900, 1500 2500lbs
	DIN	PN6,PN10,PN16,PN25,PN40,PN64,PN100
	GOST	PN6,PN10,PN16,PN25
	EN	PN6,PN10,PN16,PN25,PN40,PN64,PN100
	JIS	1K,2K,5K,10K,16K,20K,30K,40K
	BS	PN6,PN10,PN16,PN25,PN40,PN64,PN100
	UNI	PN6,PN10,PN16,PN25,PN40
	SABS	600KPA,1000,1600,2500,4000
Size	ANSI	1/2” – 60”
	DIN	DN15-DN2000
	GOST	DN10-DN1600
	EN	DN15-DN2000
	JIS	15A-1500A
	BS	DN15-DN2000
	UNI	DN10-DN2000
	SABS	DN10-DN600
Coating	varnish, yellow paint, anti-rust oil, galvanizing etc
Usage	Used for the connection of all kinds of pipeline. to convey the water, steam, air, gas and oil
Package	Wooden cases/pallets
Delivery	Within 30 days
Certificate	ISO9001:2008

A105 Carbon Steel Weld Neck Flange RF Forging DIN Black 150# 300# 0

A105 Carbon Steel Weld Neck Flange RF Forging DIN Black 150# 300# 1

FAQ:

1.)Are you a trading company or Factory?

We are a real factory with our own producing machine and warehouse,started to do business from year 1993

2.)How long time of your longer cooperation customer?

Many customers have long cooperation with us,such as European customer cooperated with us 15years.and more.

3.)What is your advantage?

Best quality,low price,special service,each customer information record.

4.)What about your delivery time?

quantity less than 500tons,25days after get deposit,above 500tons will need 30-35 working days.
